Two of my Shelby Hamfest acquisitions were a couple of Fluke digital multimeters (DMMs) for $5 each. The seller had no idea if they were working or not, but for $10 I figured they would either be handy workbench instruments if they worked, or fun projects if they didn’t. A brief Google search brought me to a nice tear down/repair attempt blog post.
The Fluke 8000A is a pretty nice looking bench DMM with push buttons for function and range selection, and a handle that also doubles as a stand.
A printed label on the bottom provides specifications and indicates what optional features the meter has. Apparently a rechargeable battery was an available option which would have made it handy for field use. This one didn’t come with a battery.
A label on the top of the unit says this unit was last calibrated in September 1994, 27 years ago. Someone apparently decided at some point the meter wasn’t working properly anymore and wrote “BAD” on the sticker.
Much to my surprise, the meter turned on when I plugged it in. Testing with some precision resistors I have in my collection gave me some pretty good results.
Measuring the DC voltages of some batteries gave me results that compared pretty well with one of my handheld meters. I haven’t tried measuring anything else yet, but it seems like for $5, I’ve got a pretty decently functioning bench meter (at least for most of the things I’d need to do anyway).
Undoing four screws at the back of the unit releases the back (surprise!) and top cover to reveal the inside.
The back plate has the power supply consisting of two chunky transformers, a fan, and DB25 connector. There’s also an empty spot for another DB25 connector. Thanks to the two transformers, the rear panel is fairly hefty. The DB25 connector looks like it only has 4 wires. Not sure what would be connected to it, but probably something serial terminal related. There’s not a lot of clearance between the transformers and the SRAM chips on the main board when the rear panel is in place.
Removing the expansion board (I’ll get to that in a bit) reveals the main board.
The Motorola MC6800 CPU that powers the 680 is up toward the expansion board connector. Toward the bottom rear of the main board are 8 1kbit Intel P2102 SRAM chips that provides the 680 with 1 kB of RAM. Above the RAM is an EPROM (looks like an AM 1702A EPROM). The empty sockets seem like they would provide space for 3 more EPROMs. The other notable chip on the main board is the MC6850 asynchronous communications interface adapter.
Over in the front corner of the board by the big 3.3 mF filtering capacitor, the silk screen says this 680 main board is Rev 1-6.
The only expansion board in this 680 appears to be a RAM expansion board. The riser card has room for 3 slots, but the two other spots are unpopulated.
The RAM board contains an 8×4 bank of Semi 4200UCP chips. A Google search didn’t yield a whole lot of information about them, but they appear to be 4kbit SRAM chips, so this board provides the Altair with a whopping 16 kB of additional memory to play with.
When I plugged it in and turned it on, the fan spun up and some lights came on!
No smoke released, but the data lights turning on even though most of the switches were in the down position indicates something’s not quite right. Changing the switch positions didn’t affect anything either. The Run light on even though the switch is in the HLT position also suggests something isn’t quite right. Toggling the HLT/RUN switch made the HLT LED blink on once. Toggling the RESET switch didn’t seem to affect anything. The address line switches all seem to work, but LEDs started blinking when A13 was switched on.
Looks like this unit might need some work to restore it to a functioning state. I’ll also need to do some more research to learn about how the 680 works.
One of the items donated to the radio club by an SK estate last year (now I’ve forgotten which one) was this microprocessor training laboratory (MTL-1) from Cleveland Institute of Electronics (CIE).
Presumably, if you had an interest in learning computer hardware and programming, you’d enroll in a class and get one of these along with class materials. I’ve seen similar trainers in the past, but never had the opportunity to use them. The breadboard area lets you wire up circuits that let you do things with the 6809.
This one is based on a Motorola MC6809, a contemporary of the 6502 and Z80 microprocessors. After watching the one YouTube video I’ve found along with a bit of random button pressing, I’ve managed to figure out how to to go to different addresses and enter assembly code. I haven’t entered anything that runs though. I’ll have to find some time to learn 6809 assembly first.
Aside from the copyright date on the back, there’s no other indication of when this particular unit dates to. Fun fact: 1984 was my first year of high school,
Surprisingly, I’ve found very little documentation about this particular trainer online. I’ve found one video on YouTube where someone used it to demonstrate testing a RAM chip, and a few photos of similar units on auction sites, but nothing in the way of manuals or even course materials that might have used the trainer.
This seems like it would be a fun thing to play with, especially for anyone with a retro-computing fetish. The hunt for documentation continues. I’ve already found a few PDFs about programming the 6809, so maybe I’ll be able to figure out enough do fun things with this.
In the parts bins that I acquired long ago, four of the many ICs in one of the bins were Z80 microprocessors. At the time, I thought it would be neat to try to do something with them, but had no time and no levels in low level hardware design.
Fast forward to post-PhD time and inspired by Ben Eater‘s 8-bit CPU and 6502 projects and videos, I learned enough about microprocessors and what connections to make with them to try doing something with the Z80. YouTube also presented me with a variety of Z80 related videos to watch. This one by Julian Ilett was one I found particularly informative.
The date codes on the Z80 chips indicates they’re 1987-1988 era chips, and not knowing how they were stored before I got them, I had no idea if any of them even worked. Grabbed one of the Z80 chips, plunked it into a breadboard and started wiring it up.
Off in the corner of the breadboard is a 555 set up as an astable oscillator and functions as the clock for the Z80. The clock goes runs between 6 – 475 Hz depending on the potentiometer setting.
After getting things wired up and applying power, some LEDs would light up, but then all the address bus LEDs would blink on and off but not in the expected binary counting pattern. Seemed like I had everything wired up correctly.
After studying Julian’s video and wiring some more, I tried triggering the reset pin and boom! LEDs blinked off, then came back on and the address bus LEDs started the expected binary counting pattern! Yay, it worked! Added a button for the reset pin to make resetting the Z80 easier.
Getting this going was fun, and a good learning experience. Gained a few XPs.
What next? Well, I could continue on and try to add enough to make a functional computer out of the Z80 and following the techniques in Ben’s 6502 video series. I’ll definitely need some more breadboards, and a few more components. I’ve got a few RAM chips I could try, but no idea of any of them actually work.
It’s kind of cool just turning it on and watching the LEDs blink though.
Making a breadboard based Z80 computer would be a fun project.
